AccuWeb MICRO 4000 NET - Sensor Setup and Configuration; Sensor Model Setup Table

Setup
The following table lists all sensor models and the corresponding values for controller parameters
12, 13, 24, 25, 36, and 37. Refer to page 17 for more information about setting controller
para
meters. Refer to page 60 for more information about the Digital Line Guide.
Sensor
Type
Sensor Model
Number
Sensing Area
Width
inches [mm]
Guide Point Parameter
Adjust Range
inches [mm]
12, 13,
or 49
Parameter
24 or 25
Parameter
36 or 37
Parameter
Notes
55 or 56
1.5x3U 4043-XX 0.2 [5] 0.06 [1.6] 1 2 x 0
3x3U 4050-XX 0.2 [5] 0.06 [1.6] 1 2 x 0
4x6U 4060-XX 0.2 [5] 0.06 [1.6] 1 2 x 0
PointSource
Ultrasonic
E/D
4x12U 4090-XX 0.2 [5] 0.06 [1.6] 1 2 x 0
1.5x4U 4510-XX 1.8 [46] 1.6 [41] 1 12 0 0
1.5x5U 4511-XX 2.6 [66] 2.4 [61] 1 16 0 0
4x5U 4500-XX 2.6 [66] 2.4 [61] 1 16 1 0
4x9U 4520-XX 6.6 [168] 6.4 [163] 1 36 1 0
4x14U 4530-XX 11.4 [290] 11.2 [284] 1 60 1 0
Ultrasonic
WideArray
E/D
4x21U 4540-XX 18.6 [472] 18.4 [467] 1 96 1 0
Hi-Temp
Ultrasonic
E/D
UT 4068-XX 0.2 [5] 0.06 [1.6] 1 2 x 2 see note 1
1.5x3L 4044-XX 0.2 [5] 0.06 [1.6] 1 2 x 1
PointSource
Infrared
E/D
3x3L 4051-XX 0.2 [5] 0.06 [1.6] 1 2 x 1
1.5x3.75L 4611-XX 1.4 [36] 1.2 [30] 1 10 0 1
4x3.75L 4620-XX 1.4 [36] 1.2 [30] 1 10 1 1
Infrared
WideArray
E/D
4x14L 4532-XX 11.4 [290] 11.2 [284] 1 60 1 1
Digital
Line
Guide
P/E 5100-XX 0.63 [16] 0.43 [11] 2 x x x
In the table above, x indicates don’t care or not used.
1
The Hi-Temp edge detector is compatible only with the MICRO 4000 NET controller.
PointSource™, WideArray™, and Hi-Temp Edge Detectors
