Appendix 6 / Discrete Isolated Outputs
The discrete isolated outputs allow the MICRO 4000 NET system status to be remotely monitored
by a customer's PLC. There are five status outputs: IN LIMIT, OUT LIMIT, SERVO-CENTER
LIMIT, AUTO MODE, and NO FAULT. All outputs are opto-isolated.
Warning: It is the responsibility of the customer to insure machine safety. Changing the
mode of operation from any source - front-panel switchpad, fieldbus, or Discrete Isolated
Inputs - can cause machine motion.
Electrical Specifications:
Discrete Isolated Outputs (per output)
Maximum customer-supplied voltage 31 VDC between any two terminals
Off-state leakage current 1.0 uA maximum
On-state resistance 2.5 ohms maximum
On-state continuous current 0.4 ADC maximum
On-state peak current 1.2 ADC for 100 msec, repeatable
every 2 seconds
Isolation 30 VAC max. between any terminal
and ground
MICRO 4000
NET Controller
48
