The oscillation function is configured by the following parameters. Refer to page 17 for more
informatio
n about setting controller parameters.
Oscillation Mode
3 1 0
The oscillation function is off. This is the default setting.
3 1 1
The oscillation function is on.
3 1 2
The oscillation function is on and the oscillation speed can be varied
from the minimum speed (parameter 53) to the maximum speed
(parameter 33) by using the Analog Input 1.
3 1 3
The oscillation function is on and the oscillation speed can be varied
from the minimum speed (parameter 53) to the maximum speed
(parameter 33 ) by using the Analog Input 2.
3 1 4
The oscillation function is on. The actuator will oscillate between the In
and Out end-of-travel limits. This mode will not work with MX-series
actuators.
Oscillation Total Travel
3 2 7. 5 0
This parameter sets the guide point’s range of travel distance. This
range is symmetrical around the system’s fixed guide point. The position
of the fixed guide point can be adjusted with the optional Remote
Station. The range is from 0 to 7.50 inches (or 3.75 inches max). The
default setting is 1.00 inch ( 0.50 inch).
Oscillation Maximum Speed
3 3 1. 0
This parameter sets the guide point’s maximum oscillation speed. The
range is from 0 to 25.5 inches per minute. The default setting is 1.0
inch per minute.
Oscillation Speed Multiplier
3 4 5 0
This parameter scales the guide point’s oscillation speed by a fixed
percentage. The range is from 0 to 100%. The default setting is 50%.
Oscillation Minimum Speed
5 3 1. 0
This parameter sets the guide point’s minimum oscillation speed. The
range is from 0 to 25.5 inches per minute. The default setting is 1.0
inch per minute.
MICRO 4000
NET Controller
44
