Introduction
The Guide Point Adjust Remote Station provides a convenient method of adjusting the system’s
guide point from a remote location.
The Guide Point Adjust Remote Station is compatible with the following controllers:
MICRO 4000 NET or MICRO 1000 Controllers
The Guide Point Adjust Remote Station requires an interface cable to connect to these
controlle
rs. Cables are available in standard lengths of 12’ [3.6m], 25’ [7.6m], 50’ [15.2
m], 75’ [22.8m], and 100’ [30.5m].
The Guide Point Adjust Remote Station also requires a Serial I/O board (AUX 4249) to
con
nect to the MICRO 1000 Controller.
Product Specifications:
Remote Station size (H x W x D): 2.52” [64mm] x 3.86” [98mm] x 1.41” [36mm]
Power requirements: Supplied by controller
Operating
environment:
Maximum ambient temperature 120 deg F [48.9 deg C]
Humidity 0-90%, Non-condensing
Installation
The Remote Station can be mounted in a variety of ways. The enclosure design allows the user
to easily remove the rear housing for panel-mount applications. Refer to the application drawings
and connection diagrams on page
137 for installation information.
Remote Station - Guide Point Adjust
89
