AccuWeb MICRO 4000 NET - Line Guide Test Pattern; Test Pattern Diagram

Appendix 2 / Line Guide Test Pattern
Use this test pattern to verify the proper installation and operation of the Digital Line Guide:
Test pattern
Web direction
Sensor cable location
AccuBeam 3 Digital Line Guide Sensor
82
