Operation:
Discrete Isolated Outputs (DC COMMON is connector J10 terminal 7)
Connector
Output Description
J10 terminal
This output is on when the actuator has reached the In limit and is off
during normal operation. This output does not function if a MX-series
actuator is installed.
1
IN LIMIT
This output is on when the actuator has reached the Out limit and is off
during normal operation. This output does not function if a MX-series
actuator is installed.
2
OUT LIMIT
This output is on when the actuator is at the servo-center position and is
off during normal operation.
3
SERVO-CENTER
This output is on when the controller is operating in Automatic mode and
is off during all other modes of operation.
4
AUTO MODE
This output is on when the controller is ready to operate and is off when
any of the following conditions occur:
The controller is displaying an error code. Refer to page 42 for more
informatio
n about error codes.
5
NO FAULT
AC power is off.
An edge-loss or line-loss condition occurs. This option is enabled by
setting parameter 47. Refer to page 17 for more information about
setting contro
ller parameters.
This output is controlled by parameter 58. Refer to page 17 for more
informatio
n about setting controller parameters.
6
AUXILIARY
MICRO 4000
NET Controller
49
