AccuWeb MICRO 4000 NET - Example 1: Sensor Input from Another Controller

Example # 1: Input a sensor signal from another MICRO 4000 NET controller:
In this example controller # 1’s analog input is
configured to receive a sensor signal from
controller # 2.

Find the model number of controller # 2’s sensor in Table 1 and enter the
corresponding parameter values into controller # 1.
If the sensor signal is connected to Analog Input 1, then enter the values into
para
meters 43 and 44.
If the sensor signal is connected to Analog Input 2, then enter the values into
para
meters 45 and 46.
Refer to page 17 for more information about setting these parameters.

Configure controller # 2 to output its sensor signal through one of its analog outputs
(set parameter 38 or 39).
Table 1
Sensor
Type
Sensing Area
Sensor Model Parameter Parameter
Width
Number
inches [mm]
43 or 45 44 or 46
1.5x3U 4043-XX 0.20 [5] 0 20
3x3U 4050-XX 0.20 [5] 0 20
4x6U 4060-XX 0.20 [5] 0 20
PointSource
Ultrasonic
E/D
4x12U 4090-XX 0.20 [5] 0 20
1.5x4U 4510-XX 1.8 [46] 1 80
1.5x5U 4511-XX 2.6 [66] 2 60
4x5U 4500-XX 2.6 [66] 2 60
4x9U 4520-XX 6.6 [168] 6 60
4x14U 4530-XX 11.4 [290] 11 40
Ultrasonic
WideArray
E/D
4x21U 4540-XX 18.6 [472] 18 60
Hi-Temp
Ultrasonic
E/D
UT 4068-XX 0.20 [5] 0 20
1.5x3L 4044-XX 0.20 [5] 0 20
PointSource
Infrared
E/D
3x3L 4051-XX 0.20 [5] 0 20
1.5x3.75L 4611-XX 1.4 [36] 1 40
4x3.75L 4620-XX 1.4 [36] 1 40
Infrared
WideArray
E/D
4x14L 4532-XX 11.4 [290] 11 40
Digital
Line
Guide
P/E 5100-XX 0.63 [16] 0 63
MICRO 4000

NET Controller
51
