AccuWeb MICRO 4000 NET - Example 2: Third-Party Sensor Voltage Input

Example # 2: Input a voltage from a third-party sensor:
Calculate the Analog Input Scale Fa
ctor using the formula below.
Analog Input Scale Factor = 100  F
 S

If the sensor is connected to Analog Input 1, then enter the result into parameters 43
and 44.
If the sensor is connected to Analog Input 2, then enter the result into parameters 45
and 46.
Refer to page 17 for more information about setting these parameters.
F = Full-scale input range (volts).

If the sensor is connected to Analog Input 1, then the value of F is determined by
parameter 41, as shown in Table 2.
If the sensor is connected to Analog Input 2, then the value of F
is determined by
parameter 42, as shown in Table 3.
S = Sensor o
utput scale factor (volts-per-inch).
Table 2
Parameter Full-Scale
41 Input Range
0 input 1 is off
1 5
2 10
3 20
Table 3
Parameter Full-Scale
42 Input Range
0 see note below
1 5
2 10
3 20
Note: If parameter 2 (end-of-travel mode) is set to 1, then F = 5. If parameter 2 is not set
to 1, then input 2 is off.
MICRO 4000

NET Controller
53
