AccuWeb MICRO 4000 NET - Page 97

Bit definitions:
Job Profile Read-Only Backlight Start-Up not used not used not used not used not used not used not used not used not used not used not used not used Offset 1 Offset 2 Hidden Units
Bit number
19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Hex digit
fifth fourth third second first
Hexadecimal (hex) conversion:
Bit-field Hex digit
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
0 0 1 1 3
0 1 0 0 4
0 1 0 1 5
0 1 1 0 6
0 1 1 1 7
1 0 0 0 8
1 0 0 1 9
1 0 1 0 A
1 0 1 1 B
1 1 0 0 C
1 1 0 1 D
1 1 1 0 E
1 1 1 1 F
Example: Offset 2, Backlight, Hidden, Read-O
nly, and Start-up parameters are hidden
Job Profile Read-Only Backlight Start-Up not used not used not used not used not used not used not used not used not used not used not used not used Offset 1 Offset 2 Hidden Units
Bit settings
0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1 1 1 1
Hex digits
0 0 0 2 F
Remote Station - Guide Point Adjust
94
