22 Chapter 1
Keyboard
Battery
LCD 14.1”
NOTE: 5 points position (Display area: 303.7 (H) x 189.8(V)mm)
Item Specification
Keyboard controller ENE KB926
Total number of keypads 88-/89-/93-key
Windows logo key Yes
Internal & external keyboard work
simultaneously
Plug USB keyboard to the USB port directly: Yes
Item Specification
Vendor & model name Sanyo Sony
Battery Type TM-2007A Li-Ion TM-2007A Li-Ion
Pack capacity 4400mAh 7200mAh
Number of battery cell 6 9
Package configuration 3S2P 3S3P
Item Specification
Vendor/model name AUO B141EW04 V3/V4
Screen Diagonal (mm) 357.7 (14.1 W”)
Active Area (mm) 303.7(H) x 189.8 (V)
Display resolution (pixels) 1280x3(RGB) x 800
Pixel Pitch 0.237
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
Typical White Luminance (cd/m
2
)
also called Brightness
200 Typ. (5 points average)
170 Min. (5 points average)
(see note below)
Luminance Uniformity 1.3 max. (5 points)
Contrast Ratio 500:1 Typ.,300:1 Min.
Response Time (Optical Rise
Time/Fall Time) msec
16 Typ., 25 Max.
Nominal Input Voltage VDD +3.3 Typ.
Typical Power Consumption (watt) 5.2 Typ.
Weight (without inverter) 400 g Typ., 420g Max.
Physical Size (mm) 320 max. (W) x 206 max. (H) x 5.5 max.(T).
Electrical Interface R/G/B Data, 3 Sync, Signals, Clock (4 pairs
LVDS)
Support Color 262K colors (RGB 6-bit)
Viewing Angle (degree)
Horizontal: Right/Left
Vertical: Upper/Lower
Min. 40 Typ. 45
Min. 10 Typ. 35
Temperature Range (°C)
Operating
Storage (shipping)
0 to +50
-20 to +60
