Chapter 1 23
LCD Camera
LCD Inverter
AC Adapter
System Power Management
Item Specification
Vendor Sertek Inc Chicony
Focusing range 40 cm to infinity 27 cm to infinity
Dimension (L x W x H mm) 65* 9.0 * 5.30+/-0.20 mm 65±0.2 * 9±0.1 * 5.4±0.25 mm
Sensor OV7725 CMOS Sensor
350K Pixel
VGA CMOS sensor
Pixel Resolution 640 X 480 640 X 480
Image Size 3.98mm(H) X 2.95mm(V) Up to VGA resolution
Item Specification
Vendor & model name YEC YNV-C01H
Input voltage (V) 9 ~ 20
Input current (mA) 0.08 ~ 0.6
Output voltage (V, rms) Typical 680
Output current (mA, rms) 2.0 ~ 6.8 (mA)
Output voltage frequency (KHz) 45~70
Item Specification
Input rating 100~240Vac,50~60 Hz
Maximum input AC current 1.7A
Inrush current No damage
Efficiency Meet EPA Energy Star level-4 requirement
Item Specification
Features
• Suspend to RAM or Suspend to Disk mode, by time out
or by hot key
• HDD Local Stand-By mode by time out
• LCD Local Stand-By mode by time out
• Low battery alarm by beep
• Auto-backlight off when LCD cover closed
• Full ACPI 1.0B supported
• LCD Auto-DIM mode by time out
