Acer P1200 - Assemble Bottom Shielding and IO Cover Module

P1100C/P1200i/P1200B
Condential
2-21
2-18 Assemble Bottom
Shielding and IO Cover
Module
1. Fasten 2 tenons (as green rectangle) to
assemble IO Cover.
2-17 Assemble ElevatorElevator
Foot Rubber
1. Assemble the Elevator Foot Rubber (as
red rectangle).
