Acer P1200 - Chapter 3 Troubleshooting; Chapter 4 Function Test & Alignment Procedure

P1100C/P1200i/P1200B
Condential
iv
Assemble System Fan Module and the Blower Module 2-24
Assemble DMD Chip and DMD Board 2-26
Assemble Engine Module 2-27
Assemble Color Wheel Module 2-28
Assemble Front Cover Module 2-29
Assemble Main Board Module and the Blower Module 2-29
Assemble Keypad Board Module and Zoom Ring 2-32
Assemble Top Cover Module 2-33
Assemble Lamp Module 2-34
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Main Procedure 3-2
Beep Sound 3-6
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode 4-1
OSD Reset 4-1
Test Condition 4-2
Test Inspection Procedure 4-3
PC Mode 4-4
PC Calibration 4-7
Video Performance 4-9
Optical Performance Measure 4-10
Restore Blower Speed 4-12
Color Wheel Index Adjustment 4-12
USB Port Test 4-13
Network Function Test 4-14
