Part II. Installing the Receiver
This chapter explains how to connect the Receiver to an HDTV. Make sure you have all the
contents from the Receiver’s package available before starting.
2.1. Connecting the Receiver to an HDTV
It is quite easy and fast to set up the Receiver. You can complete the connection in just one
minute.
To connect the Receiver to an HDTV:
1. Get the Receiver, AC power adapter, and HDMI cable from the Receiver’s package.
2. Plug one end of the HDMI cable into the HDMI port (“Video Out” or “HDMI-OUT”) on the
Receiver, and the other end into an available HDMI port on the HDTV.
3. Plug the connector of the power cord to the Receiver’s power input port labeled "5V DC"
or “POWER”, and plug the power adapter to a power outlet.
When Steps 1, 2, and 3 are complete, the hardware should be connected as shown in
the figure below:
4. Turn on the HDTV and set it to display the input from the correct HDMI port (the one you
have plugged into in Step 2).
5. Verify that the “Ready to connect” screen appears on the HDTV.
