Page #88 background image
Table 1.1
7 ON = _____________
This field determines what happens when the LED status light associated with
Button 7 is turned ON.
Generally if the button is set to ON MODE and the relay it controls is
ON, the LED will turn ON as well. This also applies to the opposite
mode: if the button is set to OFF MODE and the relay it controls is OFF,
the LED will also generally turn ON (the only exceptions are if the logic
of the Status LEDs are changed as described later in this guide).
Note that there is no physical Button 7 or physical Status LED for Button 7 on a
Chelsea Digital Switch. So Buttons 7-14 are virtual buttons used for
programming purposes only, and the associated Status LEDs are also just virtual
placeholders that are turned on and off. Usually, virtual Buttons 7 and 8 will be
set to operate a spare relay or an empty relay position rather than a relay with a
connected load.
Possible Values Result
Normal
(default value)
None. Setting this value to “Normal” in a Chelsea Digital
Switch means that nothing will happen when the virtual
LED associated with Button 7 is turned ON.
BTS 1-6 < 9 - 14 When the virtual LED associated with Button 7 is ON, the
programming for buttons 1-6 will be replaced with the
programming for buttons 9-14. When the LED is OFF,
buttons 1-6 will revert to their original programming.
BTS 1-3 < 9 - 11 When the virtual LED associated with Button 7 is ON, the
programming for buttons 1-3 will be replaced with the
programming for buttons 9-11. When the relay is OFF,
buttons 1-3 will revert to their original programming.
BEEP When the virtual LED associated with Button 7 is ON, the
switch will make a beeping sound. Highlighting the word
BEEP and pressing ENTER will allow you to set the beep
pattern.
Locator When the virtual LED associated with Button 7 is ON, the
switch’s Locator LED will flash. Highlighting the word
Locator and pressing ENTER will allow you to set the
flash pattern.
Disable 1-6 When the virtual LED associated with Button 7 is ON,
buttons 1-6 will be disabled.
Disable 1-14 For a Chelsea Switch, this has the same effect as “Disable
1-6”. However, when programming a Digilink, it allows
all Digilink inputs (1-14) to be disabled.
Beep + Locator When the virtual LED associated with Button 7 is ON, the
switch will make a beeping sound and the Locator LED
will flash. Highlighting the words Beep + Locator and
pressing ENTER will allow you to set the beep and flash
pattern.
- 4 -
88
