Page 27
USER MENU
REVIEW SCHEDULE
MANUAL OVERRIDE
SETUP MENU
The field on the right says UNUSED f o r schedules that have
not yet been programmed and cannot be entered yet. Once
a schedule has been entered this field becomes available to
enter the GROUP that the schedule will control. Schedules
may only control groups and there are 32 available groups
in the system.
If several schedules have already been entered then use
the Tab key to highlight the schedule that you wish to
review or change and press ENTER.
This will bring up the Schedule with the highlight on the first
field.
The Default is EVERYDAY. Scrolling on this field gives
options of MON-FRI and BY-DAY which are explained
later.
THE USER MENU
Pressing any key on the opening page display will take you
to the USER MENU.
MANUAL OVERRIDE is the m enu for changing the status of
any load.
REVIEW SCHEDULE is the menu for both programming
new schedules and changing existing schedules.
The SETUP MENU leads to all the other menus of the sys-
tem. The other three items on the menu are discussed later.
Review/Changing a Schedule
Pressing ENTER with REVIEW SCHEDULE highlighted
will take you to the Schedules Menu. There are 32 available
schedules which are displayed on 6 pages. Scrolling up or
down on the PAGE 1-6 highlight will take you through the 6
pages of schedules.
SCHEDULES
ON TIME: 09:00am
OFF TIME: 05:00pm
Use TAB UP or DOWN to select a schedule to edit and
then press ENTER. Note that the name of the schedule
being highlighted pops up at the top of the page as you tab
down. This name is set up in the NAMING MENU.
USER MENU
MANUAL CONTROL
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWIT CH
iDIM/iDH SCENES
SETUP MENU
Versions of the Clock before V2.14
show some of the menu items on
different pages
V 2.0 and earlier
To Next Page
