7451A/7461A/7461P Digital Multimeter Operation Manual
6.7.3 ADC Command Reference
6-26
Item Command Description
Initial
value
Measurement
condition
Measurement range 7461A/61P
DCV ACV ACV
(AC+DC)
2W 4W DCI ACI ACI
(AC+DC)
LP-
2W
LP-
4W
Freq
R0
AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO
R3
100 mV 100 mV 100 mV 100  100  - - - 100  100  (100 mV)
R4
1000 mV 1000 mV 1000 mV 1000  1000  1000 A 1000 A 1000 A 1000  1000  (1000 mV)
R5
10 V 10 V 10 V 10 k 10 k 10 mA 10 mA 10 mA 10 k 10 k (10 V)
R6
100 V 100 V 100 V 100 k 100 k 100 mA 100 mA 100 mA 100 k 100 k (100 V)
R7
1000V 700 V 700 V 1000 k 1000 k 1000 mA 1000 mA 1000 mA 1000 k 1000 k (700 V)
R8
---10 M 10 M 3 A 3 A 3 A 10 M 10 M -
R9
---100 M 100 M ------
R? Reply: One of R0, R3 to R9
7451A
DCV ACV ACV
(AC+DC)
2W 4W DCI ACI ACI
(AC+DC)
LP-
2W
LP-
4W
Freq
R0
AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO AUTO
R2
--- 30  30  ------
R3
300 mV 300 mV 300 mV 300  300  - - - 300  300  (300 mV)
R4
3000 mV 3000 mV 3000 mV 3000  3000  3000 A 3000 A 3000 A 3000  3000  (3000 mV)
R5
30 V 30 V 30 V 30 k 30 k 30 mA 30 mA 30 mA 30 k 30 k (30 V)
R6
300 V 300 V 300 V 300 k 300 k 300 mA 300 mA 300 mA 300 k 300 k (300 V)
R7
1000 V 700 V 700 V 3000 k 3000 k 3000 mA 3000 mA 3000 mA 3000 k 3000 k (700 V)
R8
---30 M 30 M ---30 M 30 M -
R9
---300 M 300 M ------
R? Reply: One of R0, R2 to R9
Range Fix RX Range switching from AUTO to MANUAL
Sampling rate PR0 FREE (PR0 is returned when the sampling interval or integration time is
changed.)
PR1 FAST1
PR2 FAST2 (The same as PR1 in the frequency measurement)
PR3 MED
PR4 SLOW1
PR5 SLOW2 (The same as PR4 in the frequency measurement)
PR? Reply: One of PR0 to PR5
