7.1.10 Measurement Time and Display Digits
7-17
7.1.10 Measurement Time and Display Digits
Maximum measurement speed and its conditions
Sampling rate
Measurement speed (In Auto-range OFF)
Integration
time
Auto-zero
DCV
Bch-DCV
DCI
2W
LP-2W
4W
LP-4W
ACV
ACI
Continuity
Diode
ACV(AC+DC)
ACI(AC+DC)
FAST1 1000 times/s *1 110 times/s 400 times/s 4 times/s 0.02 PLC OFF
FAST2 300 times/s *1 80 times/s 250 times/s 4 times/s 0.1 PLC OFF
MED 20 times/s 20 times/s 20 times/s 3 times/s 1 PLC ON
SLOW1 4.5 times/s 4.5 times/s 4.5 times/s 2 times/s 5 PLC ON
SLOW2 2 times/s 2 times/s 2 times/s 1 time/s 10 PLC ON
*1 Under the following conditions
Trigger source: BUS, EXT, MAN
Sampling count: 2 or more
Complete signal output mode: SINGLE
Display: OFF, Calculation: OFF, Measurement data memory: ON
7461A/61P 7451A
Measurement speed 20,000 times/s 5,000 times/s
Target function DCV, DCV-Bch, DCI, 2W, LP-2W
Integration time 10 s 100 s
Sampling interval 50 s 200 s
Other *1
*1 Under the following conditions
Auto-range: OFF
Trigger source: BUS, EXT, MAN
Sampling count: 2 to 16,000
Complete signal output mode:
SINGLE
Display: OFF
Measurement data memory:
ON
7451A/61A: Up to 10,000 data
7461P: Up to 16,000 data
