7451A/7461A/7461P Digital Multimeter Operation Manual
4.2.1 Measurement Functions
4-10
Figure 4-7 Resistance Measurement (2W, 4W, LP-2W, and LP-4W)
Table 4-8 Maximum Allowable Applied Voltage (2W, 4W, LP-2W, LP-4W)
Between  and COM 1000 Vpeak *1
Between 4WHI and LO 200 Vpeak
Between 4WHI/LO and COM 200 Vpeak
Between COM and chassis 500 V
*1: If an over-voltage is applied, the internal circuits may be separated from the input ter-
minals by the protection function.
Current
