7451A/7461A/7461P Digital Multimeter Operation Manual
5.10 Saving and Loading the Measurement Condition Settings
5-46
5.10 Saving and Loading the Measurement Condition Settings
In this instrument, four files of measurement condition setting parameters can be saved in non-volatile mem-
ory USER0 to USER3.
For information on setting parameters, refer to Section 8.9, “System Recovery Procedure” and “Table 8-6
Initial Values of Setting Parameters.”
5.10.1 Auto-Loading when Turning on the Power
This instrument starts under the stored conditions when the power is turned off.
If the same startup conditions are always used, the measurement conditions stored in USER0 can be loaded
when the power is turned on.
Select from the followings in ‘PON.LD’ in the category in .
P.OFF Starts this instrument under the measurement conditions stored
when the power is turned off.
USER0 Loads the measurement conditions in USER0.
Press to apply the setting.
5.10.2 Saving the Setting Parameters
Select a memory from USER0 to USER3 in ‘SAVE’ in the category in
.
Press to save the setting parameters into the selected memory.
5.10.3 Loading the Setting Parameters
Select a memory from USER0 to USER3 and DFLT in ‘LOAD’ in the
category in .
Press to load the setting parameters from the selected memory.
If DFLT is selected, the initial values are loaded.
For more information on initial values, refer to Section 8.9, “System Recovery Proce-
dure”.
