7451A/7461A/7461P Digital Multimeter Operation Manual

8.3.3 Calibration Point

8-5

8.3.3 Calibration Point

1. Perform calibration for each range of each measurement function. For more information on relation-

ships between functions and ranges, refer to Table 5-2.

2. First, calibrate the zero point in each range calibration.

3. In the DC voltage measurement (includes DCV-Bch) and DC current measurement, calibrate the zero

point and full-scale point.

4. In the resistance measurement, calibrate the zero point and full-scale point for 4W measurement

and calibrate only zero point for 2W measurement.

5. In the low-power resistance measurement, calibrate the zero point and full-scale point for 4W mea-

surement and calibrate only zero point for 2W measurement.

6. In the AC voltage measurement and AC current measurement, calibrate the zero, 1/100 full-scale, 1/

10 full-scale, and full-scale points.

7. In the ACV(AC+DC) and ACI(AC+DC) measurements, no calibration is required because the instru-

ment is calibrated when the calibration is performed in the DC voltage and AC voltage measurements.

8. In the continuity, diode and temperature measurement, no calibration is required because the instru-

ment is calibrated when the calibration is performed in the DC voltage and AC voltage measurements.

9. In the frequency measurement, no calibration is required.

Table 8-2 Calibration Point (7461A/61P) (1 of 2)

Measurement

function

Range Zero Calibration point1 Calibration point2 Calibration point3

DCV 100 mV Short +100 mV - -

1000 mV Short +1000 mV - -

10 V Short +10 V - -

100 V Short +100 V - -

1000 V Short +1000 V - -

ACV

ACV(AC+DC)

100 mV Short 1 mV, 1 kHz 10 mV, 1 kHz 100 mV, 1 kHz

1000 mV Short 10 mV, 1 kHz 100 mV, 1 kHz 1000 mV, 1 kHz

10 V Short 100 mV, 1 kHz 1000 mV, 1 kHz 10 V, 1 kHz

100 V Short 1000 mV, 1 kHz 10 V, 1 kHz 100 V, 1 kHz

700 V Short 7 V, 1 kHz 70 V, 1 kHz 700 V, 1 kHz

DCI 1000 A Open +1000 A- -

10 mA Open +10 mA - -

100 mA Open +100 mA - -

1000 mA Open +1000 mA - -

3 A Open +3 A - -
