7451A/7461A/7461P Digital Multimeter Operation Manual
5.9.3 Scaling Calculation
5-36
3. Setting the numerical value of the constant
The setting ranges of Constants A, B, and C are shown below.
1. In the constant setting mode, the following items, which blink, can be selected by
using and .
• From the most significant digit to the least significant digit in the numeric
value
• Unit prefix
• Decimal point
2. Change the numeric value and unit prefix by using and .
The unit prefix cycles through the following order.
p n m No unit prefix k M G T
Press the key in this mode if setting the measurement value as the scal-
ing constant.
3. Press to apply the setting.
4. S OL (scaling over)
“S OL” is displayed If the scaling calculation result exceeds the values of 999.9999E + 6
(999.999E + 6 for 7451A)
In this time, the measurement range is not changed to the upper range even if the measurement range
is set to Auto-range.
(Auto-range is determined according to the measurement value acquired before the calculation is per-
formed.)
5. Canceling the scaling calculation
The scaling calculation is canceled when any of the following conditions occur.
• OFF is selected from the MATH item in while the scaling calculation is performed.
• The measurement function is changed.
• The *RST command is executed.
• The dB or dBm calculation is performed.
• The trigger source is set to LEVEL or DELTA.
Constant Setting range
Minimum
resolution
7461A/61P
A
-9999999.E +6 to +9999999.E + 6
0.000001E - 9
B
0.000000E - 9
C
7451A
A
-999999.E +6 to +999999.E + 6
0.000001E - 9
B
0.000000E - 9
C
The exponential part is set by using a unit prefix (p, n, , m, k, M, G, T).
