22
Group 4 — Option 5 External Bells and Strobe in Part Set
This option determines whether the External Bell and Strobe outputs activate during an
alarm condition when the system is Part Set. During an alarm condition, External Bell and
Strobe outputs activate when enabled (1), when disabled (0) they do not.
This option defaults to 1 (enabled).
Note: Internal sounders always sound.
Group 4 — Option 6 External Bells and Strobe in Night Set
This option determines whether the External Bell and Strobe outputs activate during an
alarm condition when the system is Night Set. During an alarm condition, External Bell
and Strobe outputs activate when enabled (1), when disabled (0) they do not.
This option defaults to 1(enabled).
Note: Internal sounders always sound.
Group 4 — Option 7 Alarm Trigger Output
This option determines the operation of the Trigger output, marked TRIG on TB1, .
This option has three settings:
1. 0 V Detector Reset
This output type is used to provide the negative supply to devices such as sensors. The 0 V
supply is removed for five seconds when the setting procedure is initiated to ensure de-
vices are reset before the system sets. After an alarm activation, the 0 V will be removed
when the system is reset to clear any latched conditions.
2. Set Latch Positive
This output type is used with latching PIRs. The output is set to 0 V switching to 12 V
when the first of the following occur:
• Alarm Condition.
• Entry Timer is Started.
• System is Unset.
Table 3.9 Part Set Exit Warning : 442
Keypad and Sounder
Table 3.8 Part Set Exit Warning : 441
Buzzer Only
—GNINRAWTIXETESTRAP YLNOREZZUBDAPYEK144
ENOTTIXE
TLUAF
ENOT
TLUAF
TAENOT
FODNE
EMITTIXE
TROFMOC
ENOT
teStraPylnodapyeKylnodapyeKylnodapyeKylnodapyeK
teSthgiNenoNenoNylnodapyeKylnodapyeK
—GNINRAWTIXETESTRAP DNAREZZUBDAPYEK244
REDNUOSLANRETNI
ENOTTIXE
TLUAF
ENOT
TLUAF
TAENOT
FODNE
EMITTIXE
TROFMOC
ENOT
teStraPhtoBhtoBhtoBhtoB
teSthgiNenoNenoNhtoBhtoB
