Safewatch Pro 3000 Installation Instructions
5-2
PROMPT VALID ENTRIES EXPLANATION
10 Zone Type
Perimeter 03
Zone Type (ZT)
00-25, 77, 90, 91 = zone type
(see table at right; types 92/93
only programmable via
downloader)
Each zone must be assigned to a zone type, which defines the way in
which the system responds to faults in that zone.
Enter the Zone Type code from the list below:
Note: If 00 is entered, Delete Zone ? will be displayed.
00 = Not used 07 = 24-Hr Audible 20 = Arm–STAY*
01 = Entry/exit #1 08 = 24-Hr Aux 21 = Arm–AWAY*
02 = Entry/exit #2 09 = Fire 22 = Disarm*
03 = Perimeter 10 = Interior w/Delay
23 = No Alarm Resp*
04 = Interior Follower 12 = Monitor Zone 24 = Silent Burglary
05 = Trouble Day/Alarm Night 14 = Carbon Monoxide 25 = 24-Hr Non-Alarm
06 = 24-Hr Silent 16 = Fire w/Verify 77 = Keyswitch
*5800 button-type transmitters only 90-93 = Configurable
10 Partition
1
Partition No. (P)
1-3 = partition (3 = common)
[
∗
] to continue
Enter the Partition number for this zone. Partition 1 is shown
entered.
10 Report Code
1st 01 2nd 00 10
Report Code (RC)
First Digit:
01
†
= enable CID report
00 = disable CID report
Second Digit: entries ignored
[
∗
] to continue
Entering any non-zero entry as the first digit enables the Contact ID
report code for this zone. Refer to the
System Communication
section for information about report codes and formats.
† typical entry
02 HARDWIRE TYPE
EOL 0
Hardwire Type
0 = EOL
1 = NC
2 = NO
[
∗
] to continue
This prompt appears only for zone numbers 02-08.
Zone 1 is automatically set for EOL operation.
02 Response Time
1
Response Time (RT)
0 = 10mSec
1 = 350mSec
2 = 700mSec
3 = 1.2 seconds
[
∗
] to continue
This prompt appears only for hard-wired zones 01-08 (zone 02 is used
as an example in display).
Option 3: used for “clean me” option on zone 1 (see field
∗
174).
10 INPUT TYPE
RF TRANS 3
Input Device type (In)
2 = AW (Aux wired zone)
3 = RF (supervised RF
transmitter,
4 = UR (unsupervised RF
transmitter)
5 = Button type RF transmitter
(unsupervised).
[
∗
] to continue
All of the RF transmitters have one or more unique factory-assigned
input (loop) ID codes. Each of the inputs requires its own
programming zone
(e.g., a 5804's four inputs require four
programming zones).
RF Transmitters can be enrolled as one of the following types:
Type Description
“RF” Sends periodic check-in signals, as well as
(Supervised RF) fault, restore, and low-battery signals. The
transmitter must stay within receiver's range.
“UR” Sends all the signals that the “RF” type
(Unsupervised RF) does, but the control does not supervise the
check-in signals. The transmitter may therefore
be carried off-premises.
“BR” (Unsupervised Sends only fault signals. It will not send a
Button RF) low-battery signal until it is activated. The
transmitter may be carried off-premises.
Note:
For the built-in hardwired zones, the Input Device type is
automatically displayed as HW and cannot be edited.
To Next Page
