Adtech ADT-CNC4620 User Manual

Adtech CNC Technology Co., Ltd. 11. Program saving & editing
- 58 -
Unit : LOGIC VOLTAGE LEVEL
Authority : Operation admin or higher
Default : 0
Effective time : Instant
Note : Set the effective voltage level of the system safety signal. The source of
safety signal can be customized by the user, and generally may be
electric cabinet door and similar sensitive occasions. If there are several
insecure places, please connect the signals in parallel to safety signal test
pin of the system.
Considering the convenience of maintenance, safety signals are checked
only when the system starts processing, and won’t prompt in idle state.
067 Pressure Signal ELevel
Range : 0~1
Unit : LOGIC VOLTAGE LEVEL
Authority : Operation admin or higher
Default : 0
Effective time : Instant
Note : Set the effective voltage level of system air pressure alarm
Both air pressure alarm and emergency stop alarm are effective globally.
073 SpindleAlarm ELevel
074 TransduserAlarm ELevel
068 ChuckSignal ELevel
Range : 0~1
Unit : LOGIC VOLTAGE LEVEL
Authority : Operation admin or higher
Default : 0
Effective time : Instant
Note : The above alarms are checked while the system is running. The system
alarms once the test is valid.
This port is affected by IO configuration.
069 OilPressure Open(min)
070 OilPressure Keep(sec)
071 OilPressureOut Freq(Hz)
Range :
Unit :
Authority : Operation admin or higher
Default : 0
Effective time : Instant
Note : Set the schedule start and holding time of the automatic oil pump of the
system
Schedule open setting is that the oil pump outputs (OUT10) when the
timing reaches specified value after the system starts and times.
Output signal stops keeping for the seconds specified by P1.070 (reverse
phase).
Output signal follows the hertz specified by P1.071 in working state, and
used for oil supply devices. If it is set to 0, the system will keep low
output level.
072 OilInspect ELevel
Range : 0~1
Unit : LOGIC VOLTAGE LEVEL
Authority : Operation admin or higher
Default : 0
Effective time : Instant
Note : Lubricant pressure test is performed automatically when the lubricant
output of the system completes.
The system alarms immediately if no oil pressure in place signal is
detected after lubricant output.
This port is affected by IO configuration.
