Adtech ADT-CNC4620 User Manual

ADT-CNC46XX 系列维护手册
- 84 -
Default input port configuration of M series (milling machine)
Wire
No.
Definition Function
1 IN0 X axis zero point
2 IN1 Y axis zero point
3 IN2 Z axis zero point
4 IN3 A axis zero point
5 IN4 Tool regulator in place test
6 IN5 Security door test input
7 IN6 System under-voltage alarm input
8 IN7 System lubricant pressure alarm input
9 IN8 Standby input
10 IN9 Standby input
11 IN10 System material clamping alarm input
12 IN11 Standby input
13 IN12 Standby input
14 IN13 Standby input
15 IN14 Standby input
16 IN15 Standby input
17 IN16 (XLMT-) X axis negative limit (standby IN32)
18 IN17 (XLMT+) X axis positive limit (standby IN33)
19 IN18 (YLMT-) Y axis negative limit (standby IN34)
20 IN19 (YLMT+) Y axis positive limit (standby IN35)
21 IN20 (ZLMT-) Z axis negative limit (standby IN36)
22 IN21 (ZLMT+) Z axis positive limit (standby IN37)
23 IN22 (ALMT-) A axis negative limit (standby IN38)
24 IN23 (ALMT+) A axis positive limit (standby IN39)
25 INCOM
Input common end INCOM (24V+, 12V+) connects
to internal or external power supply
