Adtech ADT-CNC4620 User Manual

Adtech CNC Technology Co., Ltd. 12. Hardware interface definition and connection instructions
- 87 -
Default output port configuration of M series (milling machine)
Wire No. Definition Function
1 OUT0 Principal axis positive rotation (M03)
2 OUT1 Principal axis reverse rotation (M04)
3 OUT2 Standby output (M56, M57)
4 OUT3 Standby output (M58, M59)
5 OUT4 Cooling (M08, M09)
6 OUT5 Lubricating (M32, M33)
7 OUT6 Standby output (M10, M11)
8 OUT7 Timing oil pump output of the system
9 OUT8 Standby output (M12, M13)
10 OUT9 Standby output (M14, M15)
11 OUT10 Standby output (M16, M17)
12 OUT11 Standby output (M18, M19)
13 OUT12 Standby output (M40, M41)
14 OUT13 Standby output (M42, M43)
15 OUT14 Standby output (M44, M45)
16 OUT15 Standby output (M46, M47)
17 OUT16 Standby output (M48, M49)
18 OUT17 Standby output (M50, M51)
19 OUT18 Alarm indicator
20 OUT19 Running indicator
21 OUT20 Variable frequency speed switch 3 (M66, M67)
22 OUT21 Variable frequency speed switch 2 (M64, M65)
23 OUT22 Variable frequency speed switch 1 (M62, M63)
24 OUT23 Variable frequency speed switch 0 (M60, M61)
25
OUTGND12V-, 24V- common power supply of
external output
