Adtech ADT-CNC4620 User Manual

ADT-CNC46XX 系列维护手册
- 88 -
Default output port configuration of L series (lathe)
Wire No. Definition Function
1 OUT0 Principal axis positive rotation (M03)
2 OUT1 Principal axis reverse rotation (M04)
3 OUT2 Tool regulator positive rotation output (M56, M57)
4 OUT3
Tool regulator reverse rotation & locking output
(M58, M59)
5 OUT4 Cooling (M08, M09)
6 OUT5 Lubricating (M32, M33)
7 OUT6 Standby output (M10, M11)
8 OUT7 Standby output (M20, M21)
9 OUT8 Chuck locking (M12)
10 OUT9 Chuck loosening (M13)
11 OUT10 Standby output (M16, M17)
12 OUT11 Standby output (M18, M19)
13 OUT12 Standby output (M40, M41)
14 OUT13 Standby output (M42, M43)
15 OUT14 Standby output (M44, M45)
16 OUT15 Standby output (M46, M47)
17 OUT16 Standby output (M48, M49)
18 OUT17 Standby output (M50, M51)
19 OUT18 Standby output
20 OUT19 Standby output
21 OUT20 Variable frequency speed switch 3 (M66, M67)
22 OUT21 Variable frequency speed switch 2 (M64, M65)
23 OUT22 Variable frequency speed switch 1 (M62, M63)
24 OUT23 Variable frequency speed switch 0 (M60, M61)
25
OUTGND12V-, 24V- common power supply of
external output

Adtech ADT-CNC4620 Specifications

General

Brand	Adtech
Model	ADT-CNC4620
Category	Controller
Language	English
