ADTECH9 Series CNC Maintenance Manual
- 145 -
028 X physial Assign Num<●>
Y physial Assign Num<●>
Z physial Assign Num<●>
A physial Assign Num<●>
B physial Assign Num<●>
C physial Assign Num<●>
Range : 0~4
Unit : Pulse port sequence No.
Authority : Super Admin
Default :
Effective time : Restart
Note : In default mode, the actual number of every axis corresponds to the silk
screen number on the shell. If certain function axis is abnormal, you can
replace the axis through this function. For example, set P2.045 to 4,
P2.048 to 1, then, any operation to X axis will be the operation to A axis
encoder port on the shell.
0: no such axis
1~6: corresponding to 1#-6# axis
029 X axis encoder wire number
Y axis encoder wire number
Z axis encoder wire number
A axes encoder wire number
B axis encoder wire number
C axis encoder wire number
Range : 0~9999
Unit : Wire number
Authority : Super Admin
Default : 2500
Effective time : Instant
Note : Set the encoder wires connected to every pulse port (AB phase pulse).
Since four times frequency division is performed for internal transfer, the
