Adtech CNC9650 User Manual

ADTECH9 Series CNC Maintenance Manual
- 196 -
8 IN7 (A_LMT-) A axis negative limit IN07
9 INCOM1
Input common end (24v+,
12v+)
+24V
10
IN8（X_STOP0）
X axis zero point
IN08
11
IN9（Y_STOP0）
Y Axis Home IN09
12 IN10 (Z_STOP0) Z Axis Home IN10
13 IN11(A_STOP0) Z Axis Home IN11
14 IN12(B_STOP0) B Axis Home IN12
15 IN13(C_STOP0) C Axis Home IN13
16 IN14 Standby input IN14
17 IN15 Standby input IN15
18 INCOM2
Input common end (24v+,
12v+)
+24V
19 IN16 B axis positive limit IN16
20 IN17 B axis negative limit IN17
21 IN18 C axis positive limit IN18
22 IN19 C axis negative limit IN19
23 IN20 Standby input IN20
24 IN21 Standby input IN21
25 IN22 Standby input IN22
26 IN23 Standby input IN23
27 INCOM3 Input common end(24v+, 12v+) +24V
28 IN24 Standby input IN24
29 IN25 Standby input IN25
30 IN26 Standby input IN26
31 IN27 Standby input IN27
32 IN28 Standby input IN28
33 IN29 Standby input IN29
34 IN30 Standby input IN30
35 IN31 Standby input IN31
36 INCOM4
Input common end (24v+,
12v+)
+24V
