ADTECH9 Series CNC Maintenance Manual
- 197 -
37
Default Extended input port configuration of 99M series XS14 (CNC9960 milling machine)
Extended digital input interfaces are mainly used for spare extension, which is defined in the following figure
Wire No. Port Definition Function
1 IN32 Standby input
2 IN33 Standby input
3 IN34 Standby input
4 IN35 Standby input
5 IN36 Standby input
6 IN37 Standby input
7 IN38 Standby input
8 IN39 Standby input
9 IN40 Standby input
10 IN41 Standby input
11 IN42 Standby input
12 IN43 Standby input
13 IN44 Standby input
14 IN45 Standby input
15 IN46 Standby input
16 IN47 Standby input
17 IN48 Standby input
