Page 6 of 42
1.4 EN54 Functions
This Control Panel is compliant with the requirements of EN54 parts 2 and 4 (1997).
In addition to the basic requirements, the following optional functions are provided
and these comply with the requirements of EN54.
CIE Optional Functions EN54-2 Clause
Indication
Outputs
Controls
Outputs to Fire Alarm Devices
Co-incidence Detection
Alarm Counter
Test Condition
7.8
7.12
7.13
10
P.S.E Functions EN54-4 Clause
Operation from a main power supply
Operation from a standby battery
Monitor and Charge the Standby Battery
Recognise and Notify Supply Faults
5.1
5.2
5.3
5.4
This Fire Alarm Control Panel also supports additional functions that are not covered
by EN54. These are as follows:
Additional Function
Refer to
Paragraphs
Auxiliary Power Supply Output
Auxiliary Relay Outputs
2.3.4.3
2.3.4.1
1.5 EN54 Optional Features with Requirements
In addition to the mandatory requirements of EN54 Part 2, the Control and Indicating Equipment
(CIE) supports the following optional features with requirements: -
Section 7.8
Outputs to Fire Alarm Devices.
The CIE has provision for connection to Fire Alarm Devices. It is possible to Silence
and Resound the alarms at Level 2. Refer to the User Manual for further information.
Refer to Sections 2.3.4.5 and 3.3.2 for information on installation and output
programming.
Section 7.13
Alarm Counter.
The CIE has provision record the number of times that the fire alarm condition is
entered. Refer to the User Manual for further information.
