Section 10
Test Condition.
The CIE has provision for testing the installation on a per zone basis. Refer to the
User Manual for further information.
1.6 EN12094-1 Optional Features with Requirements
In addition to the mandatory requirements of EN12094-1, the Extinguishing Control Device (ECD)
supports the following optional features with requirements: -
Section 4.17
Delay of Extinguishing Signal.
The ECD has provision to delay the transmission of the extinguishing signal. This can
be programmed in 1-second intervals up to a maximum of 60-seconds. Refer to
Section 3.3.3.1 for programming.
Section 4.18
Monitor Flow of Extinguishing Agent.
The ECD has provision to monitor the flow of the extinguishing agent once released.
One fixed input is provided. Programmable inputs can also be configured as hold
inputs. Refer to Sections 2.3.4.6, 3.3.4 and 3.3.3.1.
Section 4.19
Monitor of Status of Extinguishing Components.
The ECD has the provision to monitor the status of extinguishing components such as
loss of agent, temperature, etc. Refer to Sections 2.3.4.6, 3.3.4 and 3.3.3.1.
Means shall be provided to transmit the information concerning the blocked position
of a manual control device. Refer to sections 2.3.4.1 and 3.3.5 for further information.
Section 4.20
Emergency Hold Device.
The ECD has provision for an emergency hold device. Refer to Sections 2.3.4.6, 3.3.4
and 3.3.3.1.
Means shall be provided to transmit the information concerning the activation of an
emergency hold device. Refer to sections 2.3.4.1 and 3.3.5 for further information.
Section 4.21
Control of Flooding Time.
The ECD has provision to control the duration of the flooding time. Refer to Section
3.3.3.1 for programming.
Section 4.23
Manual Only Mode.
The ECD has provision to switch from Auto/Manual to Manual Only means of
establishing the extinguishing signal. This can be by Level 2 User Menu Option, fixed
input, programmable input or by Key-Switch Option. Refer to Sections 2.3.4.6, 3.3.4
and 3.3.3.1.
