Heat Transfer Fluid—The heat transfer fluid supplied with the instru-
ment should be installed as described in section G. Spare supplies of
heat transfer fluid may be stored at room temperature.
Sample Tubes—Glass tubes may be cleaned in a standard dishwash-
er, observing the usual precautions against breakage of light-weight
glass items. The standard plastic cassettes, however, may distort under
extended exposure to high heat.
Sample Tube Cassettes—Do not expose the sample cassettes to tem-
peratures above 180°F (82°C).
4
The Advanced
®
Model 4C3 User’s Guide
Figure 3: Major Parts and Controls
MEASUREMENT &
CONTROL CIRCUIT
BOARDS (INSIDE)
DISPLAY PANEL
& KEYPAD
PRINTER
DOOR
CASSETTE
DECK COVER
AIR FILTERS
THERMOELECTRIC
REFRIGERATION
(INSIDE)
