K. Setup
Your 4C3 has been setup at the factory for normal operation, but
the SETUP menu may be required for changing the date and time or
customizing the setup parameters for your own individual needs.
NOTES a. The supervisor/operator keyswitch must
be in the Supervisor position to enable the use of the
SETUP menu. If the SETUP button is pressed while
the supervisor/operator keyswitch is in the operator
position, a “Supervisor Key Needed; Press
Stop to Continue” message will be displayed.
b. The instrument setup is stored in firmware which can
easily be updated at the factory to incorporate possi-
ble additional setup items or refinements. The follow-
ing list includes all currently implemented setup func-
tions in the order in which they appear in the SETUP
menu; however, the order in which they appear may
change slightly if the firmware is later updated to
include additional SETUP items.
The operating parameters that may be checked and set via the setup
menu are listed in table 5.
Enter SETUP, if required, by pressing the SETUP button. When
SETUP is pressed, the display will change to “Select Setup
Item”.
There are two ways to select a SETUP menu item, direct selection
and sequential selection, described as follows:
0. Select Setup Item
This menu item is displayed first when SETUP is pressed, and
allows either direct selection or sequential selection of a menu
item.
19
Installation & Setup
