7. A small port for draining the insert test well and any liquid
spills in the deck area is located under the left center of the
instrument. A shallow sponge or tray such as one of the 4C3035
cassette storage trays may be placed under the drain port to
catch any vented liquid.
8. Remove the fluid ship plug (solid) from the heat transfer fluid
port (see figure 5). Install the vented fluid fill plug provided
with the instrument.
NOTE Save and store the solid fluid ship plug. If the instru-
ment is returned for any reason, the vented fluid fill
plug must be removed and the solid fluid ship plug
re-installed as part of the preparations for shipment.
E. Load printer paper
A roll of thermal printer paper and a paper roll holder are supplied
with the instrument, as illustrated on the packing list. These must be
installed in the printer, as follows:
1. Unroll 6-8” (25-30 cm) of paper from the paper roll.
2. Fold one corner of the end of the paper to form a 4-6” (15-25
cm), blunt-tipped, tapered point. Crease the fold so that the dou-
bled part will not be thicker than two thicknesses of paper.
3. Open the printer door (see figure 3) by pulling the top of the
door forward and down.
4. Feed the folded tip of the paper from the top of the roll (as
shown in figure 6) into the slot at the back of the printer.
CAUTION The paper should only be pushed or pulled forward
through the printer; attempting to pull the paper back-
ward through the printer may cause printer damage.
7
Installation & Setup
