5. Push the paper in far enough for the end to slightly protrude
from the paper output slot in the printer door.
6. Grasp the protruding tip of paper and gently pull 2-4” (8-15 cm)
straight out of the slot in the printer door while, with the other
hand, centering the paper being drawn in.
CAUTION If the paper is not carefully centered as it is being
drawn into the printer, its edges may fray or tear, caus-
ing the paper to jam in the printer.
If the printer paper becomes jammed under the print
head, a protective circuit will shut off the printer with-
out deactivating the display or the rest of the instru-
ment.
To reactivate the printer, shut off the 4C3. Clear the
paper jam and turn the power back on. If the paper jam
has been successfully cleared, the instrument will com-
plete the power-up cycle described in section H and
reactivate the printer.
7. Insert the paper-roll holder into the paper roll, center it and drop
the roller ends into the roller slots (see figure 6).
8. Pull enough paper through the printer to take up any slack
between the paper roll and the printer.
8
The Advanced
®
Model 4C3 User’s Guide
Figure 6: Loading Printer Paper
