MOTOR (5 PIN MOLEX)
CHASSIS GROUNDGREENGRN /
YEL
MOTOR STARTER CAP. PIN-3BLBL
IF/BD-J5 PIN-2 MOTOR STARTER CAP. PIN-1WHITEBLK
JUMPED TO PIN-1BLACKBL
IF/BD-J5 PIN-14BLACKBLK
SOLENOID AIR VALVES (2 PIN MOLEX)
SAV-1 (MAIN SEAL PRES.)
PLC OUTPUT-PIN-27WHT/BLK/REDBLK
IF/BD-J4 PIN-1YELBLK
SAV-2 (HEATER SEAL BOARD)
PLC OUTPUT-PIN-25WHT/BLK/BRNBLK
IF/BD-J4 PIN-1YELBLK
SAV-3 (LOAD SHELF)
PLC OUTPUT-PIN-11WHT/BRNBLK
IF/BD-J4 PIN-1YELBLK
SAV-4 (BAG LIFT)
PLC OUTPUT-PIN-9 AND IF/BD J2-PIN-8WHT/BLK/GRNBLK
IF/BD-J4 PIN-1YELBLK
SAV-5 (TRIM SEAL)
PLC OUTPUT-PIN-23WHT/BLK/VOLBLK
IF/BD-J4 PIN-1YELBLK
SAV-6 (PERF BREAK)
PLC OUTPUT-PIN-24WHT/BLK/GRYBLK
IF/BD-J4 PIN-1YELBLK
SAV-7 (FLAT SEAL)
PLC OUTPUT-PIN-26WHT/BLK/BLBLK
IF/BD-J4 PIN-1YELBLK
SAV-8 (ACCUM. FUNNEL)
PLC OUTPUT-PIN-8WHT/BLK/YELBLK2
IF/BD-J4 PIN-1YELBLK1
SAV-9 (VENTURI BLOWER)
PLC OUTPUT-PIN-12WHT/BLKBLK
IF/BD-J4 PIN-1YELBLK
SAV-10 (AIR PULSE)
PLC OUTPUT-PIN-13WHT/BLBLK
IF/BD-J4 PIN-1YELBLK
TOUCH SCREEN (CABLE 4 CONT.)
IF/BD J1-PIN-3,4GRNPIN-
IF/BD J1-PIN-6REDPIN+
HIGH VOLTAGE BOARD
J-1 (6 PIN CONN)
IF/BD-J3 PIN-5ORGPIN-3
T-2 PIN-10 XFMRBLKPIN-2
IF/BD-J5 PIN-7BLUEPIN-1
140
