8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland www.advancedsensors.co.uk
Page 9 of 93
OIW-HBO-0002-EX-005
OIW EX SERIES-SIDE STREAM
OPERATION MANUAL
Rev. 004 MAY 2015
1.6 OPTICAL SAFETY
The system uses a Class 3R laser as part of its measurement process. The light from this source is contained within the
measurement chamber and is safe during normal operation. Power to the laser, or the unit, should not be applied when
the unit is disassembled. Use caution when the cover is removed from the inspection window to prevent direct eye
exposure.
The labelling and the location of this on the side of the unit, is shown in Figure 1 below:
Figure 1: Location of Class 3R laser warning label.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
1.7 - AUDIO SAFETY
The system uses an ultrasonic based cleaning technology, which will operate periodically to remove oil deposits adhering
to the reading window within the chamber. When the ultrasonic device is in operation noise levels may exceed safe
limits therefore it is recommended that ear protection shall be worn when working on the system or in the vicinity.
WARNING: The area shall be sign posted to indicate high noise levels and recommend suitable PPE (ear
protection) be worn.
