OIW EX SERIES-SIDE STREAM
OPERATION MANUAL
Rev. 004 MAY 2015
A
PPENDIX
1
T
ECHNICAL
D
ATA
Measurement Performance
Measurement principle Laser Induced Fluorescence (LIF)
Range 0 - 20,000ppm
* User may select any desired measurement from 0-100ppb, 0-10ppm, 0-1,00ppm [...] up to 0 - 20,000ppm
Accuracy ±1% of measurement range
Repeatability > 99%
Response time < 1 Second, continuous results
Operating Conditions
Process temperature 0°C to 200°C
Process pressure 0-35 barg (180 barg optional)
Process flow 0-25 l/min (0 1000 l/min optional)
Operational ambient temperature -20°C to 55°C
Cleaning Ultrasonic (automatic)
Utilities
Power supply 110 or 230 VAC (pre configured)
Power frequency 50/60 Hz
Power consumption 60W normal, 300W peak
Instrument air 5-8 barg (for pneumatic valve; electric valve option available)
Certification
Ingress protection IP66
Enclosure material SS 316L or Aluminum
Hazardous Areas: Exd II 2 G IIB T4 ATEX, IECEx, Class 1 Div 1 (USA and Canada)
IMO MEPC-107 (49) IMO Certified, ABS, US Coast Guard, BV
Weight & Dimensions
Weight (including stand, pneumatic steel valve assembly, Aluminium Enclosure: 93.55Kg
termination box & isolation switch) Stainless Steel Enclosure: 141Kg
Dimensions 670W x 640D X 1120H mm (1112H mm for Aluminum enclosure)
Clear space 500mm front and rear
Mounting Optional stand or brackets
Communications
4-20 mA Passive
Ethernet Standard
HART, Modbus, Wireless (Wi-Fi), Extended Ethernet Optional
Remote access Standard
Internal data storage >10 years
Security Multiple level password protection
Additional Information
Flange fitting 1” ANSI RF standard (optional flange, sizes available)
Wetted parts SS 316L(option of CR22, CR25, Monel, Inconel, Hastelloy, Titanium)
Sample take off point Standard ½” NPT
Viewing window Standard
Sample Conditioning
Maintenance None - Automatic Cleaning
Gas removal, solids removal, temp. conditioning, flow control Not Required
Spectrometer Specification (EX-1000 models only)
Emission wavelength range 400-1,100nm
Resolution 0.5nm
