8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland www.advancedsensors.co.uk
Page 23 of 93
OIW-HBO-0002-EX-005
OIW EX SERIES-SIDE STREAM
OPERATION MANUAL
Rev. 004 MAY 2015
3.1.2 – MS Windows Functions of the OIW Software
The OIW-EX software retains some familiar functions associated with MS Windows. The ‘title bar’ (horizontal bar across
the top of a window) is equipped with the same buttons and corresponding functionality as all MS Windows
applications, as shown in the table below:
Button: Function:
Minimise the current window.
Reduce the current window size.
Maximise the current window.
Close or exit the current window.
At start up the software opens in full screen mode although during the routine power up sequence some screens will
appear rotated by 90
o
. Routine operation can only be performed with the software in full screen mode however the
window can be minimised when additional tasks, such as backing up data log files, are performed. The software will
continue routine operation when in the minimised state.
Once the measurement cycle has been started the Windows buttons are hidden to prevent accidentally minimising or
exiting the software. The top figure (a.) below shows when the cycle is stopped the buttons are present. The lower
figure (b.) shows when the cycle is running the buttons are no longer visible.
Cycle stopped-buttons visible
Cycle running-buttons hidden
CAUTION: During routine operation no general requirement exists to exit the software, except during
routine maintenance by authorised personal.
b
.
a
.
