8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland www.advancedsensors.co.uk
Page 37 of 93
OIW-HBO-0002-EX-005
OIW EX SERIES-SIDE STREAM
OPERATION MANUAL
Rev. 004 MAY 2015
Custom Tag: this editable field allows users to input a tag number, unit identifier or reference label up to 16 characters
long. This is then displayed under the Advanced Sensors corporate logo in the ‘Configuration Settings’ display area as
circled in the figure below.
Figure 41: Identifying the configuration and display locations of custom tags.
Enable MRM Access: tick to enable when a remote manager in use. When enabled system will send data to the Master
Remote Manager. Disable when an MRM is not in use.
Enable On Screen Keyboard: tick to enable and an on screen keyboard, as below in Figure 42, will open when any
editable field is selected. This will allow the user to input information on the touch screen without an external keyboard.
Deselect when not required.
Figure 42: On screen keyboard, Shift or Caps to toggle between.
