AIMB-503 User Manual 2
1.1 Introduction
AIMB-503 is designed with the Intel B85/H81 for industrial applications that require
both performance computing and enhanced power management capabilities. The
motherboard supports Intel Core i7-4770S 3.1 GHz/Core i5-4570S 2.9 GHz/Core i7-
4770TE 2.3 GHz/Core i5-4570TE 2.7 GHz/Core i3-4330 3.5 GHz/ Pentium G3320TE
2.3 GHz processor up to 8 MB L3 cache and DDR3 1333/1600 up to 16 GB. It has
rich I/O connectivity of 10 serial ports, 4 USB 3.0, 7 USB 2.0, dual GbE LAN and 3
SATA III/II ports.
1.2 Features
Rich I/O connectivity: Dual GbE LAN via PCIe x 1 bus, 1 x PCI 32- bit/33 MHz
PCI slots, 4 USB 3.0, 7 USB 2.0, 10 serial ports, 1 PCIe x 16, 1 PCIe x 4, and 1
PCIe x 1.
Standard Micro ATX form factor with industrial feature: The AIMB-503 is a
full featured Micro ATX motherboard with balanced expandability and perfor-
mance.
Wide selection of storage devices: SATA HDD, customers benefit from the
flexibility of using the most suitable storage device for larger capacity.
Optimized integrated graphic solution: With Intel® Flexible Display Interface,
it supports versatile display options and 32-bit 3D graphics engine.
1.3 Specifications
1.3.1 System
CPU: Intel Core 4th i7/i5/i3/Pentium
BIOS: AMI EFI 64 Mbit SPI BIOS
System chipset: Intel® B85/H81
SATA hard disk drive interface: Three on-board SATA connectors with data
transmission rate up to 600/300 MB
1.3.2 Memory
RAM: Up to 16 GB in 2 slots 240-pin DIMM sockets. Supports dual-channel
DDR3 1333/1600 MHz SDRAM.
– Supports non-ECC unbuffered DIMMs and do not support any memory con-
figuration that mixes non-ECC with ECC unbuffered DIMMs.
Note! A 32-bit OS may not fully detected 16 GB of RAM when 16 GB is
installed.
