27 AIMB-503 User Manual
Chapter 2 Connecting Peripherals
2.18 LCD Inverter Connector (INV1)
2.19 LVDS Connector (LVDS1)
INVI Inverter Power Output
Pin Pin Name
1+12V
2GND
3 ENABKL
4 VBR
5+5V
INV1
LVDS1
