Advantech AIMB-503 - VGA1; DVI-D DP1 Connector

AIMB-503 User Manual 16
DUALPWR2- Jumper for on board USB
DUALPWR3- Jumper for rear side USB & PS/2 KBMS
2.4 VGA1/ DVI-D DP1 Connector
AIMB-503 includes VGA,DVI and DP interfaces that can drive conventional
VGA,DVI and DP displays. VGA is a standard 15-pin D-SUB connector commonly
used for VGA. Pin assignments for VGA,DVI and DP connectors are detailed in
Appendix B.
Note! When USB power is switched to +5V, it can't be connected with power
KVM.
DP1VGA+DVI1
