AIMB-503 User Manual 20
2.10 Line Out, Mic In Connector (AUDIO1)
JFP2 Front panel connector
Pin Pin Name
1 SIO_SUSLED
2NC
3GND
4 #KEYLOCK
5GND
AUDIO1
