FAQ / Troubleshooting
My CAN Sensor Module doesn't seem to be outputting anything.
Confirm that your CAN bus is properly terminated and that all nodes are configured for the right bus speed. In
addition, any receiving devices/nodes must be specifically configured to receive as the Module is configured to
transmit; specifically, the CAN ID, bus speed, and number of ID bits.
Can I use the CAN Sensor Module with my AEM AQ-1, AEM CAN Gauge, or AEM ECU?
No, the CAN Sensor Module is only compatible with the CD-series dash displays and other third-party devices at
this time.
Where can I find AEM .dbc files?
AEM dbc files are available via the AEM Forum and within the AEM CD-series dash display software installer.
Please visit www.aemelectronics.com for more information and downloads.
For support, contact AEM Technical Support at 1-800-423-0046 or gentech@aemelectronics.com.
AEMnet (CAN Bus) Output
WHITE WIRE = AEMnet+ / CANH
GREEN WIRE = AEMnet- / CANL
CAN DBC definition files are available at
www.aemelectronics.com
Bus Termination
All AEMnet/CAN networks must be terminated to have
an equivalent of approximately 60 Ohms of resistance.
Generally, this means a 120 Ohm resistor connected in
parallel to AEMnet+/AEMnet- (or CANH/CANL) at both
physical ends of the bus run. Select termination via
jumper position as suitable for your network.
bit rate
Selectable via Jumper
kb/sec
format
Selectable via Jumper
bit ID
terminating resistor
Selectable via Jumper
endianness
big / Motorola
DLC
8
Unit 1:
0x500(11) / 0x0000B000 (29) at
100Hz
Unit 2:
0x600(11) / 0x0000C000(29) at
50Hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Analog1
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
1
2
Analog2
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
3
4
Analog3
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
5
6
Analog4
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
7
Unit 1:
0x501(11) / 0x0000B001 (29) at
100Hz
Unit 2:
0x601(11) / 0x0000C001 (29) at
50Hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Analog5
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
1
2
Analog6
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
3
4
Analog7
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
5
6
Analog8
16 bit unsigned
0.001 V/bit
0
0 to 65.535 V
7
Unit 1:
0x502(11) / 0x0000B002 (29) at 10Hz
Unit 2:
0x602(11) / 0x0000C002 (29) at 5Hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Analog5Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
1
2
Analog6Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
