AEM Performance Electronics CD-7 - Page 53

53
3
4
Analog7Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
5
6
Analog8Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
7
Unit 1:
0x503(11) / 0x0000B003 (29) at 10Hz
Unit 2:
0x603(11) / 0x0000C003 (29) at 5hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Analog9Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
1
2
Analog10Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
3
4
Analog11Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
5
6
Analog12Resistance
16 bit unsigned
1 Ohm/bit
0
0 to 65535 Ohm
7
Unit 1:
0x504(11) / 0x0000B004 (29) at 50Hz
Unit 2:
0x604(11) / 0x0000C004 (29) at
25hz
Byte
Label
Data Type
Scaling
Offset
Range
0
VR1
16 bit unsigned
1 Hz/bit
0
0 to 65535 Hz
1
2
VR2
16 bit unsigned
1 Hz/bit
0
0 to 65535 Hz
3
4
Tacho
16 bit unsigned
0.1 Hz/bit
0
0 to 6553.5 Hz
5
6
FuelLevel
8 bit unsigned
1 Ohm/bit
0
0 to 255 Hz
7
Battery Voltage
8 bit unsigned
0.1 V/bit
0
0 to 25.5 V
Unit 1:
0x505(11) / 0x0000B005 (29) at 50Hz
Unit 2:
0x605(11) / 0x0000C005 (29) at
25hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Digital1Frequency
16 bit unsigned
1 Hz/bit
0
0 to 65535 Hz
1
2
Digital2Frequency
16 bit unsigned
1 Hz/bit
0
0 to 65535 Hz
3
6
Digital1DutyCycle
8 bit unsigned
1 %/bit
0
0 to 255 %
7
Digital2DutyCycle
8 bit unsigned
1 %/bit
0
0 to 255 %
6
Digital1State
8 bit unsigned
1
0
0 to 255
7
Digital2State
8 bit unsigned
1
0
0 to 255
Unit 1:
0x506(11) / 0x0000B006 (29) at 50Hz
Unit 2:
0x606(11) / 0x0000C006 (29) at
25Hz
Byte
Label
Data Type
Scaling
Offset
Range
0
Digital3Frequency
16 bit unsigned
1 Hz/bit
0
0 to 65535 Hz
1
2
Digital4Frequency
16 bit unsigned
1 Hz/bit
0
0 to 65535 Hz
3
6
Digital3DutyCycle
8 bit unsigned
1 %/bit
0
0 to 255 %
7
Digital4DutyCycle
8 bit unsigned
1 %/bit
0
0 to 255 %
6
Digital3State
8 bit unsigned
1
0
0 to 255
7
Digital4State
8 bit unsigned
1
0
0 to 255
