AEMC 205 - AC Voltage Measurement; AC+DC Voltage Measurement

36
4.2.2 AC Voltage Measurement
Measurement
Range
0.15 to
59.99V
60.0 to
599.9V
600V to 1000V RMS
1400V peak
(1)
Specified
Measurement
Range
(2)
0 to 100% of the measurement range
Accuracy
0.15 to 5.99V
± (1% R +10cts)
6.00 to 59.99V
± (1% R +3cts)
± (1% R +3cts)
Resolution
0.01V
0.1V
1V
Input Impedance
10MΩ
Note (1) The display indicates "OL" above 1000V (1400V in PEAK mode).
Above 1000V (RMS), a repetitive beep indicates that the voltage
being measured is greater than the safety voltage for which the
device is guaranteed. The display indicates "OL".
- Bandwidth in AC = 3 kHz
Note (2) Any value between zero and the min. threshold of the measurement
range (0.15V) is forced to show "----" on the display.
Specific Specifications in MAX/MIN mode
(from 10Hz to 1kHz, and from 0.30V in AC):
• Accuracy: add 1% R to the values of the table above.
• Capture of the extreme: approximately 100ms.
4.2.3 AC+DC Voltage Measurement
Measurement Range (2)
0.15 to
59.99V
60.0 to
599.9V
600V to1000V RMS
(1)
1400V peak
Specified Measurement
Range
0 to 100% of the measurement range
Accuracy
0.15 to 5.99V
± (1% R +10cts)
6 to 59.99V
± (1% R +3cts)
± (1% R +3cts)
Resolution
0.01V
0.1V
1V
Input impedance
10MΩ
Note (1) The display indicates "OL" above 1000V (1400V in PEAK mode).
Above 1000V (DC or RMS), a repetitive beep indicates that the
voltage being measured is greater than the safety voltage for which
the device is guaranteed.
- Bandwidth in AC = 3 kHz
Note (2) Any value between zero and the min. threshold of the measurement
range (0.15V) is forced to "----" on the display.
