4.2.8 Continuity Measurement
Measurement Range
0.0 to 599.9Ω
Open-circuit Voltage
≤ 3.6V
Measurement Current
550µA
Accuracy
± (1% R +5cts)
Buzzer Triggering Threshold
Adjustable from 1 to 599Ω (40Ω is the default)
4.2.9 Resistance Measurement
Measurement Range
(1)
0.0 to
599.9Ω
600 to
5999Ω
6 to
59.99kΩ
Specified Measurement
Range
1 to 100% of the
measurement range
0 to 100% of the
measurement range
Accuracy
± (1% R +5cts)
Resolution
0.1Ω
1Ω
10Ω
Open-circuit Voltage
≤ 3.6V
Measurement Current
550µA
100µA
10µA
Note (1) Above the maximum display value, the display unit indicates "OL".
The "-" and "+" signs are not managed.
Specific Specifications in MAX/MIN mode:
• Accuracy: add 1% R to the values of the table above.
• Capture of the extreme: approximately 100ms.
4.2.10 Diode test
Measurement Range
0.000 to 3.199VDC
Specified Measurement Range
1 to 100% of the measurement range
Accuracy
± (1% R + 10cts)
Resolution
0.001V
Measurement Current
0.55mA
Indication: junction reversed or
open-circuit
"OL" is displayed when the measured
voltage >3.199V

Note: The "-" sign is disabled for the diode test function.
